ATEXAir Titanium
Modular bag filters for high-volume continuous duty
Ø 127 mm sleeves, lengths from 1,000 to 5,000 mm. Pulse-Jet cleaning controlled by differential pressure.
The Titanium range is ATEXAir's highest-capacity solution. Designed for industrial processes with high dust volume and continuous operation, it combines large filtration area, structural strength and automatic Pulse-Jet cleaning. Available in carbon steel and stainless. All models ship in standard or ATEX-certified EX version.
Specifications
Catalogue specification
- Filter media
- Antistatic synthetic fibre sleeves
- Sleeve diameter
- 127 mm
- Sleeve length
- 1,000 – 5,000 mm
- Cleaning
- Pulse-Jet, 0.10 – 0.15 s, differential-pressure controlled
- Construction
- Carbon steel or stainless steel
- Discharge
- Conical hopper · screw conveyor · rotary valve
- Safety zones (EX)
- Zone 20 · Zone 21 · Zone 22
- Venting (EX)
- EN 14491 explosion vent panels
- Accessories
- Ladder, handrail, level probe, airlock
Applications
Where it goes in
Certified
Designed and tested under European safety standards. EX versions ship with declaration of conformity, CE marking, single-line diagram, earthing instructions and operating manual.
Standard discharge: conical hopper, screw conveyor or rotary airlock — selected per process and dust class. EX versions ship with EN 14491 vent panels.
Order or enquire
Configure this product
Logistics pricing is set per project, so we don't list a public price yet. Tell us what you need and we'll come back with a sized quotation. Customisation is welcome, describe it under "Specific requirements".
